SKF型号参数详情
在线询价 PDF下载
  • Principal dimensions
    （mm)
    d 45
    D 100
    B 36
  • Basic load ratings
    KN
    dyc
    Cr     183
    stc
    Cor     183
  • Pu 19.6
  • Speed ratings
    rpm
    Speed Ratings 5300
    Limiting Speed 7000
  • Weight 1.4
  • Designation
    Cylindrical Bore 22309E/VA405
    Taper Bore -
  • Dimensions
    mm
    d 45
    d2
    ～     56.4
    D1
    ～     83.4
    b 5.5
    k 3
    r1,2
    Min     1.5
  • Abutment and fillet dimensions
    mm
    da
    Min     54
    Da
    Max     91
    ra
    Max     1.5
  • Value
    e 0.37
    Y1 1.8
    Y2 2.7
    Y0 1.8
  • 允许加速度1)
    仅适用于油润滑的轴承
    Rotate 97g
    Linear 29g
